Technical Information Library

  1. "Suggested Criteria to Use to Evaluate a Corrosion-Retardant Coating for Heat Exchangers" by CoreKote 2000™, 2018.

    Fourteen items to consider, from performance considerations to warranty to turn-around time.
  2. "Detailed e-Coating (electrophoretic-Coating) Process for Heat Exchangers and Radiators" by CoreKote 2000™

    Physical description of the movement of a coil through the process.
  3. "Processing Capacity" by CoreKote 2000™, 2018.

    Maximum unit size and weight.
  4. "AquaEC™ 6100 Technical Data Sheet" by AXALTA, 2015.

    A Cathodic epoxy electrocoat that offers excellent mechanical properties, superior corrosion resistance, and enhanced edge protection.
  5. Performance and Military Specs Performed by Independent Test Laboratories, 2018.

    Independent ASTM testing for meeting performance specifications and military specificaitons.
  6. "Comparison of Heat Exchanger Corrosion-Retardant Ratings" by CoreKote 2000™.

    A comparison of the properties of 5 coatings purported to offer protection of heat exchangers from corrosion.
  7. "Selection Guide: Environmental Corrosion Protection" - Carrier Study on Coatings for Heat Exchangers, by Carrier Corporation, April, 2006.

    Laboratory testing of e-Coating by Carrier and its conclusion that e-Coating is, by far, the best available technology to protect heat exchangers from corroding.
  8. Carrier Prohesion Cycle Test Results with added note by CoreKote 2000™, 2003.

    A part of the Carrier study showing that, after 100 hundred hours of an aggressive corrosion testing (Prohesion Test), that e-Coated units retain 100% of their ability to transfer heat.
  9. Magnified Image and Diagram of e-Coated Joint from Carrier Study, 2003.

    A part of the Carrier study that shows a close-up photographic image of an e-Coated tube-to-fin joint.
  10. "The Valeo™ Heat Exchanger Study" SAE Paper 920180 - Valeo Heat Exchanger Corrosion Study & 10-year Life Expectancy of E-Coated Heat Exchangers.

    A 100+ radiator unit test performed by Valeo, a large manufacturer of heat exchangers, in conjunction with the Copper Development Association, which concludes that e-Coating is the best available technology to retard corrosion on heat exchangers. It measures: rates of corrosion, air-pressure drop, loss of heat transfer (from the e-Coating's film thickness), cost analysis, environmental impact, and process impact in heat exchangers. (The original Valeo study without highlights, unedited.)
  11. "The Valeo™ Heat Exchanger Study" SAE Paper 920180 - Valeo Heat Exchanger Corrosion Study & 10-year Life Expectancy of E-Coated Heat Exchangers.

    (The original Valeo study, highlighted for quick reading.)
  12. "Cargill Earns its Salt in San Francisco Bay" John Deere Construction Review Newsletter, 2005.

    A John Deere publication with two articles about their use of e-Coated heat exchangers to retard corrosion. (We provide these e-Coated units to Deere.)
  13. "Cathodic Epoxy Electrocoat For Automotive Radiators" by Jeffrey Oravitz, Product Finishing Magazine, 2003.

    A Total Source article that concludes e-Coating to be the best technology to retard corrosion on heat exchangers.
  14. "CoreKote 2000 EXT™ Chemical Information", by CoreKote, 2021.

    Describes environments that may contribute to higher amounts of expelled corrosive materials.
  15. "CoreKote 2000 EXT™ Chemical Resistance Information", by CoreKote, 2021.

    A chart listing CoreKote 2000 EXT resistance to over 80 different chemicals.
  16. "CoreKote 2000 EXT™ Top Coat Comparison", by CoreKote, 2021.

    Describes the chemical resistance superiority of Fluoropolymer topcoats over Urethane topcoats.
